Lenovo ThinkPad Hybrid USB-C with USB-A Dock - Docking station - USB-C - GigE - 135 Watt - GB - for Tablet 10; ThinkPad L380; L480; L580; T480s; X1 Tablet; X1 Yoga; X280
- One dock for all notebooks
- Rich performance
- Enterprise manageability & simplification
|
Product Specification
- Product Code
- 4660660
- Manufacturer Ref
- 40AF0135UK
- Barcode
- 191999788311
- Brand
- Lenovo
Product Details
- Lenovo ThinkPad Hybrid USB-C with USB-A Dock - Docking station - USB-C - GigE - 135 Watt - GB - for Tablet 10; ThinkPad L380; L480; L580; T480s; X1 Tablet; X1 Yoga; X280
- One dock for all notebooks
Enhances the performance of Lenovo USB-C notebooks and tablets through USB-C connection, as well as previous generation and market notebooks through the USB-C to USB-A adaptor. - Rich performance
Provides up to dual UHD 4K display with DP and HDMI ports. Up to 10 Gbps data transfer speed on three USB3.1 gen2 ports, and rapid charging for ThinkPad family notebooks. - Enterprise manageability & simplification
Host of manageability features like PXE boot, Wake-On-Lan from sleep mode, and MAC address pass-through. Ideal for enterprise customers.
Specifications
General | |
---|---|
Product Type | Docking station |
Width | 21 cm |
Depth | 8 cm |
Height | 3 cm |
Weight | 475 g |
Localisation | English / United Kingdom |
Networking | |
Data Link Protocol | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 2 x USB 3.1 Gen 2 ¦ USB 3.1 Gen 2 with Always-on charging ¦ 1 x USB 2.0 - 4 pin USB Type A ¦ 1 x USB 3.1 Gen 2 ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 2 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 2 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x audio - headphones/microphone - mini-phone 3.5 mm 4-pole |
Miscellaneous | |
Cables Included | 1 x USB-C to USB-C / USB 3.0 type A cable - external |
Features | Security lock slot (cable lock sold separately), wake on LAN, Preboot Execution Environment (PXE) support, MAC address pass-through |
Compliant Standards | TUV, VCCI, BSMI, NOM, CB, FCC, SII, KCC, ICES, cULus, Kvalitet, EAC, RCM, Ukraine EMC DoC, LoA |
Power | |
Power Device | Power adapter |
Power Provided | 135 Watt |
Manufacturer Warranty | |
Service & Support | Limited warranty - 3 years |
Dimensions & Weight (Shipping) | |
Shipping Width | 27 cm |
Shipping Depth | 16.5 cm |
Shipping Height | 8.8 cm |
Shipping Weight | 1.35 kg |
Environmental Parameters | |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 35 °C |
Compatibility Information | |
Designed For | Lenovo Tablet 10 ¦ Lenovo ThinkPad L380 20M6 ¦ Lenovo ThinkPad L480 20LS, 20LT ¦ Lenovo ThinkPad L580 20LW, 20LX ¦ Lenovo ThinkPad T480s 20L7, 20L8 ¦ Lenovo ThinkPad X1 Tablet 20KJ, 20KK ¦ Lenovo ThinkPad X1 Yoga 20JD, 20JE, 20JF, 20JG, 20LD, 20LE, 20LF, 20LG ¦ Lenovo ThinkPad X280 20KE, 20KF |
